Color:
Includes: EM-120 workshop press frame, Electric hydraulic system, Manual operation controls
Does Not Include: Press tooling, Dies, Additional accessories
Built for industrial fabrication and maintenance shops that require high force pressing capability for large components.
The Laguna Tools EM-120 is a heavy duty workshop press designed for demanding pressing operations such as installing bearings, removing shafts, straightening components, and forming metal parts. With a 120 ton capacity, the press is intended for industrial environments where high force and controlled ram movement are required.
The press supports both manual and electric operation so the operator can control pressing force depending on the job requirements. A traversing head allows the ram to be positioned across the frame which helps align the pressing point with the workpiece during setup.
In real shop use this type of press is commonly used for heavy equipment repair, fabrication work, and industrial maintenance where large parts must be pressed, straightened, or assembled.
Capacity: 120 Tons
Operation Type: Manual and Electric
Ram Travel: 400 mm
Head Type: Traversing head USED FOR
Not For
A 120 ton workshop press is intended for shops that regularly perform heavy pressing operations on large or thick components. The traversing head allows the operator to align the ram with the workpiece without repositioning heavy materials during setup.
Is This Machine Right For You
You May Need A Different Machine If
Technical Specifications for the Laguna Tools Heavy Duty Workshop Press EM-120
Capacity: 120 Tons
Operation Type: Manual and Electric
Ram Travel: 400 mm
Head Type: Traversing head
Power Requirements
Electric hydraulic operation required for powered mode
Laguna Tools Heavy Duty Workshop Press EM-120 Package Includes
Upgrade options available via dropdown selections.
Compare Heavy Duty Work Shop Presses
| Model Number | EM-100 | EM-120 | EM-20 | EM-30 | EM-60 | EM-80 | M-20 | M-30 |
|---|---|---|---|---|---|---|---|---|
| Part Number | 970105 | 970114 | 970110 | 970111 | 970112 | 970113 | 970101 | 970102 |
| Capacity (tons) | 100 | 120 | 20 | 30 | 60 | 80 | 20 | 30 |
| Filter Type | Pollution Filter | Pollution Filter | Pollution Filter | Pollution Filter | Pollution Filter | Pollution Filter | Pollution Filter | Pollution Filter |
| Horsepower | 5.5 | 7.5 | 3 | 3 | 4 | 5.5 | N/A | N/A |
| Voltage | 224 V / 3 P 60 HZ | 225 V / 3 P 60 HZ | 220 V / 3 P 60 HZ | 221 V / 3 P 60 HZ | 222 V / 3 P 60 HZ | 223 V / 3 P 60 HZ | N/A | N/A |
| Width Between Uprights (in) | 40 | 47 | 27.5 | 28 | 32 | 36 | 19.5 | 23.5 |
| Min Ram To Table (in) | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 |
| Max Ram To Table (in) | 35 | 35 | 35 | 35 | 35 | 35 | 27.5 | 27.5 |
| Ram Travel (in) | 15.75 | 15.75 | 15.75 | 15.75 | 15.75 | 15.75 | 6 | 6 |
| Pressing Speed (in/min) | 19.5 | 21 | 7 mm/sec | 18 | 20 | 17.5 | N/A | N/A |
| Min Operating Pressure (PSI) | 580 | 580 | 580 | 580 | 580 | 580 | 435 | 435 |
| Max Operating Pressure (PSI) | 5801 | 5801 | 5801 | 5801 | 5801 | 5801 | 4351 | 4351 |
| Hydraulic Pump (Gal) | 6 | 4 | 1.5 | 1.5 | 2.9 | 3.17 | N/A | N/A |
| Oil Capacity (Gal) | 8 | 34 | 6.6 | 6.6 | 2 | 7 | 0.5 | 0.5 |
| Amp | 8 | 11 | 5 | 5 | 6 | 8 | N/A | N/A |
| Operation | Motor & Hand Operated | Motor & Hand Operated | Motor & Hand Operated | Motor & Hand Operated | Motor & Hand Operated | Motor & Hand Operated | Manual | Manual |
Heavy Duty Work Shop Presses User Manual
Laguna Tools - Heavy Duty Work Shop Presses EM-120 SKU: 971014_User Manual
