Color:
Includes: Heavy duty bandsaw frame, Tilting worktable, Blade welder, Blade grinder, Blade cutter, Work lamp, Chip blower, Digital tachometer
Does Not Include: Additional blades, Coolant system, Optional mist system, Optional transformer
Built for fabrication shops and production environments that need a vertical bandsaw for cutting metal components with controlled speed and accuracy.
The Laguna Tools V-16 is a vertical metal cutting bandsaw designed for fabrication and production work. The machine provides variable blade speeds so operators can match cutting speed to different materials and thicknesses.
A multi-tilting worktable supports angled cutting while the large throat capacity allows cutting larger workpieces. The saw includes an integrated blade welder, grinder, and cutter which allows operators to repair and prepare blades directly on the machine.
In real shop use this bandsaw is commonly used for cutting plate, flat stock, and formed components in fabrication shops and industrial environments where controlled vertical cutting is required.
Motor Power: 2 HP
Voltage: 220V
Blade Width: 1/8 inch to 5/8 inch
Blade Length: 123.5 inches
Blade Speed Range: 82 to 3950 ft/min
Band Wheel Diameter: 16 inches
Throat Capacity: 15.5 inches
Maximum Work Height: 10 inches USED FOR
Not For
Material Type | Cutting Capacity
Maximum Work Height | 10 inches
Throat Capacity | 15.5 inches
Maximum Output: 2 HP motor
Duty Cycle:
Designed for continuous shop operation
The V-16 vertical bandsaw is intended for shops that need flexible metal cutting for shapes, plate, and formed parts. The adjustable blade speeds allow the machine to handle different materials while the integrated blade welder helps reduce downtime when blades break.
Is This Machine Right For You
You May Need A Different Machine If
Technical Specifications for the Laguna Tools Industrial Bandsaw Model V-16
Motor Power: 2 HP
Voltage: 220V
Blade Width: 1/8 inch to 5/8 inch
Blade Length: 123.5 inches
Blade Speed Range: 82 to 3950 ft/min
Band Wheels: 2
Band Wheel Size: 16 inches
Throat Size: 15.5 inches
Maximum Work Height: 10 inches
Work Table Dimensions: 21.5 inches x 24 inches
Worktable Tilt: 15 degrees right / 12 degrees left
Work Height: 39 inches
Machine Height: 72.5 inches
Machine Floor Space: 37 inches x 26.5 inches
Weight: 904 lbs
Power Requirements
220V power required
Optional 440V operation requires step-down transformer part number 300674
Laguna Tools Industrial Bandsaw Model V-16 Package Includes
Upgrade options available via dropdown selections.
Compare Industrial Bandsaws
| Model Number | V-26E | V-26 | V-16 |
|---|---|---|---|
| Part Number | 987032-2 | 987031-2 | 987030-2 |
| Horsepower (HP) | 3 | 3 | 2 |
| Voltage | 220V | 220V | 220V |
| Blade Width (in) | 1/4 – 1 | 1/4 – 1 | 1/8 – 5/8 |
| Blade Length (in) | 184-1/4 | 184-1/4 | 123-1/2 |
| Blade Speed (fpm) | 550 – 5000 | Low 50–415 / High 550–5000 | 82 – 3950 |
| Worktable Travel Distance (in) | 12 | n/a | n/a |
| Band Wheels Number | 2 | 2 | 2 |
| Band Wheels Size (in) | 26-1/4 | 26-1/4 | 16 |
| Throat Size (Band To Column) (in) | 26 | 26 | 15-1/2 |
| Maximum Work Height (in) | 13 | 13 | 10 |
| Work Table Dimensions (in) | 23-1/2 x 27-1/2 | 23-1/2 x 27-1/2 | 21-1/2 x 24 |
| Worktable Tilt | 45° R / 10° L | 45° R / 10° L | 15° R / 12° L; 8° F / B |
| Worktable Height (in) | 39-3/8 | 39-3/8 | 39 |
| Machine Height (in) | 84 | 84 | 72-1/2 |
| Machine Floor Space (in) | 51 x 32 | 51 x 32 | 37 x 26-1/2 |
| Weight (lbs) | 1540 | 1540 | 904 |
Industrial Bandsaws User Manual
Laguna Tools - Industrial Bandsaws Model V-16 SKU: 987030-2_User Manual
Laguna Tools - Industrial Bandsaws Model V-16 SKU: 987030-2_Parts Lists
