Includes: Wood lathe, 8 inch tool rest, 3 inch faceplate
Does Not Include: Optional turning accessories, Additional turning tools
Built for woodturners who need a compact lathe with electronic variable speed and consistent torque for small turning projects.
The Laguna Revo 12 x 16 is a compact wood lathe designed for bowl turning, spindle work, and small woodworking projects. It uses a 1 HP permanent magnet DC motor controlled by a pulse width modulation system to maintain consistent torque across the full speed range.
The electronic variable speed system allows operators to work at low RPM for roughing and higher RPM for finishing. A cam action belt system provides access for speed range adjustments while the steel bed provides stability for turning operations.
In real shop use this lathe is commonly used for small bowls, pens, handles, and detailed woodworking components where a compact machine with electronic speed control is required.
Motor: 1 HP permanent magnet DC motor
Speed Control: Pulse Width Modulation controller
Input Power: 110V single phase
RPM Range Low: 50 to 525 RPM
RPM Range Mid: 325 to 1750 RPM
RPM Range High: 650 to 3500 RPM
Swing Over Bed: 12.5 inches
Distance Between Centers: 15.5 inches USED FOR
Not For
Turning Type | Capacity
Bowl Turning | Up to 12.5 inch diameter
Spindle Turning | Up to 15.5 inches between centers
Maximum Output: 1 HP motor
Duty Cycle:
Designed for continuous woodworking operation
The Revo 12 x 16 is designed for woodturners who need a compact lathe with variable speed and reliable torque at low RPM. It is commonly used for small turning projects and shops where space is limited.
Is This Machine Right For You
You May Need A Different Machine If
Technical Specifications for the Laguna Tools Wood Lathe Revo 12 x 16 Lathe
Motor: 1 HP permanent magnet DC motor
Speed Control: Pulse Width Modulation controller
Voltage: 110V
Frequency: 60 Hz
Recommended Breaker: 15 Amp
RPM Low Range: 50 to 525 RPM
RPM Mid Range: 325 to 1750 RPM
RPM High Range: 650 to 3500 RPM
Swing Over Bed: 12.5 inches
Swing Over Banjo: 9.5 inches
Maximum Outboard Swing: 16 inches
Distance Between Centers: 15.5 inches
Spindle Bore: 0.375 inches
Spindle Thread: 1 inch x 8 TPI both ends
Front Bearing: 6006LLU
Rear Bearing: 6005LLU
Indexing Positions: 24 with lock
Drive Belt: Poly V belt, 6 grooves
Tailstock Taper: MT2
Tailstock Quill Travel: 2.5 inches
Bed Length: 29.4 inches
Bed Gap: 1.25 inches
Tool Rest Length: 8 inches
Tool Rest Post Diameter: 1 inch
Faceplate Diameter: 3 inches
Certification: CSA C/US 256540
Floor to Bed Height: 6.75 inches without pads
Floor to Spindle Center: 13 inches without pads
Overall Dimensions: 35.8 x 14.6 x 20.5 inches
Net Weight: 118 lbs
Shipping Weight: 125 lbs
Shipping Dimensions: 37 x 15 x 21 inches
Power Requirements
110V single phase input
15 amp breaker recommended
NEMA 5-15P plug
6 foot power cord
Laguna Tools Wood Lathe Revo 12 x 16 Lathe Package Includes
Upgrade options available via dropdown selections.
Warranty
Refer to manufacturer documentation for warranty coverage details.
