Color:
Includes: Saw blade, Coolant system, Adjustable positive stop, Tool kit for blade changes, Instruction and service manual
Does Not Include: Optional loading table, Optional unloading table, Optional blade starter pack
Built for fabrication shops that need a semi-automatic cold saw capable of cutting ferrous metals, non-ferrous materials, and plastics.
The Laguna Tools 350SA is a semi-automatic cold saw designed for accurate cutting of metal stock in fabrication and manufacturing environments. The machine can be activated by push button or foot switch, allowing the operator to control the cutting cycle while reducing fatigue during repetitive work.
A 3.5 horsepower motor and frequency inverter allow variable blade speeds so the operator can match cutting speed to the material being processed. The rotating head allows miter cuts up to 60 degrees left and 45 degrees right while the pneumatic vise holds material securely during cutting.
In real shop use this machine is commonly used for cutting tubing, bar stock, and structural materials where repeatable cuts and controlled feed operation are required.
Motor Power: Up to 3.5 HP
Voltage: 220V
Phase: 3 Phase
Blade Diameter: Up to 14 inches
Blade Speed Range: 20 to 105 RPM
Maximum Vise Opening: 6.625 inches
Maximum Miter Angle Left: 60 degrees
Maximum Miter Angle Right: 45 degrees USED FOR
Not For
If you do not have 220V three phase power, this is not your machine.
Material Type | Cutting Capacity
Solid Round 90 degrees | 3.375 inches
Solid Round 45 degrees | 3 inches
Tube 90 degrees | 4.75 inches
Tube 45 degrees | 4 inches
Square 90 degrees | 4.125 inches
Square 45 degrees | 3.375 inches
Rectangle 90 degrees | 6.25 x 3.5 inches
Rectangle 45 degrees | 3.375 x 2.75 inches
Maximum Output: 3.5 HP motor
Duty Cycle:
Designed for continuous fabrication shop operation
The 350SA cold saw is designed for shops that need accurate cuts across a range of materials including steel, aluminum, and plastics. The semi-automatic cycle and rotating head support repetitive cutting and angled cuts in fabrication environments.
Is This Machine Right For You
You May Need A Different Machine If
Technical Specifications for the Laguna Tools Semi-Automatic Cold Saw Model 350SA
Motor Power: Up to 3.5 HP
Voltage: 220V
Phase: 3
Maximum Blade Diameter: 14 inches
Blade Speed Range: 20 to 105 RPM
Maximum Vise Opening: 6.625 inches
Maximum Miter Angle Left: 60 degrees
Maximum Miter Angle Right: 45 degrees
Solid Round Capacity 90 degrees: 3.375 inches
Solid Round Capacity 45 degrees: 3 inches
Tube Capacity 90 degrees: 4.75 inches
Tube Capacity 45 degrees: 4 inches
Square Capacity 90 degrees: 4.125 inches
Square Capacity 45 degrees: 3.375 inches
Rectangle Capacity 90 degrees: 6.25 x 3.5 inches
Rectangle Capacity 45 degrees: 3.375 x 2.75 inches
Work Height: 36.75 inches
Machine Height: 60 inches
Machine Width: 33 inches
Machine Depth: 50 inches
Weight: 890 lbs
Power Requirements
220V three phase power required
Optional transformer required for 440V model
Laguna Tools Semi-Automatic Cold Saw Model 350SA Package Includes
Upgrade options available via dropdown selections.
Warranty
Refer to manufacturer documentation for warranty coverage details.
Compare Semi-Automatic Cold Saws
| Model Number | 370S-L NON-FERROUS | 370S FERROUS | 350SA |
|---|---|---|---|
| Part Number | 976202-2 | 976200-2 | 974355 |
| Voltage | 220V | 220V | 220V |
| Horsepower | 3.5/4.5 | 3.5/4.5 | 3.5 Max |
| Cutting Ability | Non-Ferrous / Plastic | Ferrous / Non-Ferrous / Plastic | Ferrous / Non-Ferrous / Plastic |
| Maximum Blade Diameter (in) | 14–1/2 | 14–1/2 | 14 |
| Maximum Vise Opening (in) | 8–3/4 | 8–3/4 | 6–5/8 |
| Maximum Feed Vise Opening | n/a | n/a | n/a |
| Maximum Angle | 45° Left | 45° / 90° Left / Right | 60° Left / 45° Right |
| Slotting | No | Yes | No |
| Phase | 3 | 3 | 3 |
| Speeds (rpm) | 1,500 / 3,000 | 25 / 50 | 20–105 |
| Weight (lbs) | 1,360 | 1,360 | 890 |
| Solid Round 90° Capacity (in) | 4–1/4 | 4–1/4 | 3–3/8 |
| Solid Round 45° Capacity (in) | 3–5/8 | 3–5/8 | 3 |
| Tube 90° Capacity (in) | 5–1/16 | 5–1/16 | 4–3/4 |
| Tube 45° Capacity (in) | 5 | 5 | 4 |
| Square 90° Capacity (in) | 4–1/4 | 4–1/4 | 4–1/8 |
| Square 45° Capacity (in) | 3–7/8 | 3–7/8 | 3–3/8 |
| Rectangle 90° Capacity (in) | 4 x 7 | 4 x 7 | 6–1/4 x 3–1/2 |
| Rectangle 45° Capacity (in) | 4 x 6 | 4 x 6 | 3–3/8 x 2–3/4 |
| Work Height (in) | 35 | 35 | 36–3/4 |
| Height (in) | 73 | 73 | 60 |
| Width (in) | 28 | 28 | 33 |
| Depth (in) | 39 | 39 | 50 |
Semi-Automatic Cold Saws User Manual
Laguna Tools - Semi-Automatic Cold Saws Model 350SA SKU: 974355_User Manual
Laguna Tools - Semi-Automatic Cold Saws Model 350SA SKU: 974355_Parts Lists
