Color:
Includes: 1 inch die set, Digital control panel, Electric brake system
Does Not Include: Additional die sets, Tooling accessories
Built for fabrication shops that need repeatable tube and pipe bending with programmable angle control.
The Laguna Tools BM-70A is a motor driven tube bending machine designed for bending round tube and pipe with consistent radius control. The machine uses a digital control panel with microprocessor control to set bend angles and store programs for repeatable work.
A 3 horsepower motor drives the bending mechanism while an electric brake and automatic return function help position the machine for the next bend. The control system can store up to 50 programs with up to 9 bends per program which supports production work that requires repeated bend sequences.
In real shop use this machine is commonly used in fabrication shops producing handrails, frames, roll cages, and structural tube assemblies where consistent bends are required.
Motor Power: 3 HP
Voltage: 220V
Phase: 3 Phase
Material Diameter Range: 1/2 inch to 2 inches
Maximum Bend Angle: 180 degrees
Program Capacity: 50 programs with 9 bends per program USED FOR
Not For
If you do not have 220V three phase power, this is not your machine.
The BM-70A tube bender is designed for fabrication shops that need repeatable bends with programmable angle control. The digital control system allows bend sequences to be stored which helps maintain consistency when producing multiple parts.
Is This Machine Right For You
You May Need A Different Machine If
Laguna Tools Tube Bender Model BM-70A Package Includes
Upgrade options available via dropdown selections.
Laguna Tools Tube Bender Model BM-70A SKU: 962101 Specifications
| Model Number | BM-70A |
|---|---|
| Part Number | 962101 |
| Machine Type | Tube Bending Machine |
| Minimum / Maximum Material Diameter | 1/2″ – 2″ |
| Controls | Digital control panel with microprocessor and push button switch with E-stop |
| Program Capacity | 50 programs with 9 bends per program |
| Maximum Bend | 180 degrees (Infinitely variable) |
| Operation | Two handed operation Non-adjustable |
| Die Set | Easy mount for fast change over |
| Horsepower | 3 HP |
| Weight | 463 lbs |
| Size | 31.89″ x 20.28″ x 43.31″ |
| Standard Centerline Bending Radius | .12 or .15 inch |
| Voltage | 220V – 3 Phase |
Download the Laguna Tools - Tube Benders Model BM-70A SKU: 962101 User Manual
Laguna Tools - Tube Benders Model BM-70A SKU: 962101_User Manual
