Color:
Includes: Rip fence, Miter gauge, Circle cutting attachment, Work light, Blade welder, Blade grinder, Blade shear, Digital speed indicator, Blade tension indicator, Digital tachometer, Chip blower, Blade brush, 1 standard blade
Does Not Include: Optional mist system, External transformer for 440V model
Built for fabrication shops that need a vertical bandsaw with power feed table control and large cutting capacity.
The Laguna Tools V-26E is a heavy duty vertical metal cutting bandsaw designed for cutting plate, bar stock, and irregular shapes. The 26 inch throat capacity and tilting work table allow operators to position larger workpieces while maintaining stability during cutting operations.
An electronic power fed table uses a torque motor with rack and pinion drive to move the workpiece during cutting. Variable blade speeds allow the operator to match blade speed to the material being cut while a digital tachometer provides clear speed feedback.
In real shop use this machine is commonly used in fabrication shops and production environments where cutting large parts, contours, and repetitive workpieces requires controlled feed movement and adjustable cutting speeds.
Motor Power: 3 HPIf you do not have 220V power, this is not your machine.
Material Thickness | Performance
Mild Steel Plate | Up to 13 inch cutting height
Aluminum | Up to 13 inch cutting height
The V-26E vertical bandsaw is designed for shops that require controlled feed movement for repetitive cuts and larger workpieces. The power fed table and adjustable blade speeds provide flexibility for a wide range of fabrication tasks.
Is This Machine Right For You
Technical Specifications for the Laguna Tools Industrial Bandsaw Model V-26E
Horsepower: 3 HP
Voltage: 220V
Blade Width: 0.25 inch to 1 inch
Blade Length: 184.25 inches
Blade Speed Range: 550 to 5000 ft/min
Table Travel Distance: 12 inches
Band Wheels: 2
Band Wheel Size: 26.25 inches
Throat Size: 26 inches
Maximum Work Height: 13 inches
Work Table Dimensions: 21.5 x 27.5 inches
Table Tilt: 45 degrees right, 10 degrees left
Table Height: 39.375 inches
Machine Height: 84 inches
Machine Floor Space: 51 x 32 inches
Weight: 1540 lbs
Power Requirements
220V power required
3 HP motor
Laguna Tools Industrial Bandsaw Model V-26E Package Includes
Upgrade options available via dropdown selections.
Warranty
Refer to manufacturer documentation for warranty coverage details.
Compare Industrial Bandsaws
| Model Number | V-26E | V-26 | V-16 |
|---|---|---|---|
| Part Number | 987032-2 | 987031-2 | 987030-2 |
| Horsepower (HP) | 3 | 3 | 2 |
| Voltage | 220V | 220V | 220V |
| Blade Width (in) | 1/4 – 1 | 1/4 – 1 | 1/8 – 5/8 |
| Blade Length (in) | 184-1/4 | 184-1/4 | 123-1/2 |
| Blade Speed (fpm) | 550 – 5000 | Low 50–415 / High 550–5000 | 82 – 3950 |
| Worktable Travel Distance (in) | 12 | n/a | n/a |
| Band Wheels Number | 2 | 2 | 2 |
| Band Wheels Size (in) | 26-1/4 | 26-1/4 | 16 |
| Throat Size (Band To Column) (in) | 26 | 26 | 15-1/2 |
| Maximum Work Height (in) | 13 | 13 | 10 |
| Work Table Dimensions (in) | 23-1/2 x 27-1/2 | 23-1/2 x 27-1/2 | 21-1/2 x 24 |
| Worktable Tilt | 45° R / 10° L | 45° R / 10° L | 15° R / 12° L; 8° F / B |
| Worktable Height (in) | 39-3/8 | 39-3/8 | 39 |
| Machine Height (in) | 84 | 84 | 72-1/2 |
| Machine Floor Space (in) | 51 x 32 | 51 x 32 | 37 x 26-1/2 |
| Weight (lbs) | 1540 | 1540 | 904 |
Laguna Tools - Industrial Bandsaws Model V-26E SKU: 987032-2_User Manual
Laguna Tools - Industrial Bandsaws Model V-26E SKU: 987032-2_Parts Lists
